SOLARCHECK family

40

PHOENIX CONTACT 105608_en_01

SCK-M-I-8S-20A (item no. 2903241)

1 Connection terminal blocks for power

supply of optionally connected voltage

measuring module (P_OUT)

2 Analog input (0 V ... 10 V)

3 Through connections for current measure-

ment 1 ... 8 (max. 20 A per connection)

4 Snap-on foot for DIN rail mounting

5 Connection terminal blocks for digital

switching contact (D_IN)

6 Connection terminal blocks for commu-

nication cable (SCK BUS)

7 Green LED status indicator, TX: transmit

data

8 Green LED status/diagnostics indicator,

P: power supply, error diagnostics

Block diagram

P

_

O

U

T

SCK-M-I-8S-20A

Order No. 2903241

P

SCK BUS

D_IN

T

X

0

...1

0

V

U

O

U

T

U

IN

0

...1

0

V

GND2

GND1

S

T

R

IN

G

C

U

R

E

N

T

3

1

2

5

4

6

8

7

SCK-

BUS

OUT

U-IN

Digital

IN

1

+

–

2

3

4

5

6

7

8

I-IN

μ

C

COM

8x

0...10V
