Installation

105608_en_01 PHOENIX CONTACT 39

6 Installation

6.1 Connection description

SCK-C-MODBUS (item no. 2901674)

1 Connection terminal blocks for

SCK measuring modules T1 ... T4

2 Connection terminal blocks for

SCK measuring modules T5 ... T8

3 Connection terminal blocks for

+24 V DC/GND1 power supply

4 Connection terminal blocks for

RS-485 Modbus A (+)/B (-)

5 Green LED status/diagnostics indicator,

P: power supply, error diagnostics

6 Green LED status indicator, TX: transmit

data

7 Green LED status indicator, RX: receive

data

8 GND2, shield

9 Snap-on foot for DIN rail mounting

Block diagram

2

T1

T2

T4T3

+24v+

24V

GND1

G

P

T

X

R

X

SCK-C-MODBUS

Order No: 2901674

T

2

T

1

T

4

T

3

+24v

+24V

GND1

PO

W

ER

T

6

T

5

T

8

T

7

9

6

5

7

1

3

8

4

8

GND2

B

A

C

O

M

A

+24 V

B

GND1

GND2

GND1

+24 V

DC

RS-485



C

INPUT

SCK-MODBUS

T1

T2

T3

T4

T5

T6

T7

T8
