Signaling

107309_en_02 PHOENIX CONTACT 27 / 36

Table 8-2 Start and final value setting ranges

8.3 Signal output Out 13/14

Floating relay contact Out 13/14 is also used for preventive function monitoring. Different

signal dependencies can be configured as required.

8.3.1 Signal options

Select a signal option from the listed parameters:

–Output voltage

– Output current

– Output power

– Operating hours

– Temperature OK

–Input voltage OK

– Overvoltage Protection (OVP)

Additional signal option for 3AC/24DC/10A and 3AC/24DC/20A devices:

– Phase monitoring

Signal state Out 13/14 changes:

– When the current output voltage exceeds a parameterizable threshold value

– When the current output current exceeds a parameterizable threshold value

– When the current output power exceeds a parameterizable threshold value

– When the device runtime (in operating hours) exceeds a parameterizable threshold

value

– As an early warning for excessive operating temperature (> 60°C) (Temperature OK)

– If the input voltage of the power supply is interrupted for 10 ms or

– If the circuit inside the device for protecting against surge voltages is activated at the

output (Overvoltage Protection (OVP) or

– If one phase fails completely or the voltage difference between the phases is > 10 %

(Phase monitoring)

Device data

Signal option 24 V / 5 A 24 V / 10 A 24 V / 20 A 48 V /10 A

Output voltage 0 V to 32 V 0 V to 32 V 0 V to 32 V 0 V bis 60 V

Output current 0 A to 10 A 0 A to 20 A 0 A to 30 A 0 A bis 15 A

Output power 0 W to 240 W 0 W to 480 W 0 W to 720 W 0 W bis 720 W
