Signaling

107309_en_02 PHOENIX CONTACT 25 / 36

Signal state Out 2 changes:

– When the current output voltage exceeds a parameterizable threshold value

– When the current output current exceeds a parameterizable threshold value

– When the current output power exceeds a parameterizable threshold value

– When the device runtime (in operating hours) exceeds a parameterizable threshold

value

– As an early warning for excessive operating temperature (> 60°C) (Temperature OK)

– If the circuit inside the device for protecting against surge voltages is activated at the

output (Overvoltage Protection (OVP))

– If one phase fails completely or the voltage difference between the phases is > 10 %

(Phase monitoring)

Threshold value

When you select the output power, output voltage or output current signal options, a

relative threshold value is defined. You can specify the relative threshold value with 1 % ac-

curacy. The absolute threshold value is calculated automatically and displayed. The calcu-

lation of the absolute threshold values is equivalent to the calculation instructions provided

in Section 8.1, “Signal output Out 1”.

When you select the operating hours signal option, an absolute threshold value can be

set. The operating hours can be specified in increments of 0.1 h.

Output state

The signal output state is set to “High” or “Low”. The selected output state applies for as long

as the defined conditions, consisting of signal option and threshold value, are met.

Linking two signal options

You can also link two signal options together for preventive function monitoring. To do this,

select the “Extended” tab and select the “ANDing” option in the corresponding drop-down

menu.
