QUINT POWER Software

18 / 36

PHOENIX CONTACT 107309_en_02

7.1.1 Static Boost

You can disable or enable the static Boost by deactivating or activating the corresponding

check box.

Please note that when you deactivate the static Boost, the dynamic Boost and SFB Tech-

nology will also be disabled at the same time.

7.1.2 Dynamic Boost

You have the option of disabling or enabling the dynamic Boost by deactivating or activating

the corresponding check box.

Please note that when you disable the dynamic Boost, SFB Technology will also be dis-

abled. Enabling the dynamic Boost also simultaneously activates the static Boost.

7.1.3 Selective Fuse Breaking (SFB)

You can disable or enable SFB Technology by deactivating or activating the corresponding

check box.

Please note that when you enable SFB Technology, the static and dynamic Boost will be

activated at the same time.

7.1.4 FUSE MODE tripping time (tFUSE)

The FUSE MODE tripping time can be set in the range from 0.0 to 12.0 seconds in incre-

ments of 0.05 seconds.

7.1.5 FUSE MODE tripping current (IFUSE)

The FUSE MODE tripping current is specified as a percentage value in the range from 25 %

to 100 %. It can be set in increments of 1 %. The absolute tripping current is calculated au-

tomatically and displayed.
