Je bekijkt pagina 14 van 146
PLC logic
14
PHOENIX CONTACT 105868_en_01
PLC-V8C basic modules
– Basic logic module with 16 I/Os, can be extended with a maximum of two extension
modules (PLC-V8C.../EM) to 48 I/Os
– Connection to PC via micro USB socket
– Integrated realtime clock
– Accommodates external IFS-CONFSTICK memory module
– A further eight channels can be configured with corresponding PLC-INTERFACE termi-
nal blocks as digital inputs or outputs
– Optional connection to Interface system gateways
PLC-V8C basic modules 2
– Basic logic module with 16 I/Os, can be extended with a maximum of two extension
modules (PLC-V8C.../EM) to 48 I/Os
– Connection to PC via micro USB socket
– Integrated realtime clock
– Accommodates external IFS-CONFSTICK memory module
– A further eight channels can be configured with corresponding PLC-INTERFACE termi-
nal blocks as digital or analog inputs or outputs
– Optional connection to Interface system gateways
PLC-V8C extension modules
Extension logic module with 16 I/Os, for extending the basic module
Order No. Designation
2903094 PLC-V8C/SC-24DC/BM with screw connection
2905135 PLC-V8C/PT-24DC/BM with Push-in connection
Order No. Designation
2907447 PLC-V8C/SC-24DC/BM2 with screw connection
2907446 PLC-V8C/PT-24DC/BM2 with Push-in connection
Order No. Designation
2903095 PLC-V8C/SC-24DC/EM with screw connection
2905137 PLC-V8C/PT-24DC/EM with Push-in connection
