Hardware description

105868_en_01 PHOENIX CONTACT 13

2 Hardware description

The PLC-V8C logic modules are inserted in the bridge shafts of eight PLC-INTERFACE ter-

minal blocks mounted side by side on a DIN rail. All logic modules feature the following:

– Eight integrated digital inputs: two of which can be configured as analog inputs

(0 V ... 10 V)

– Connection via connector with screw or Push-in connection technology

– Programming possible using the LOGIC+ software

The following PLC-V8C types are available:

PLC-V8C stand-alone modules

– Stand-alone logic module with 16 I/Os, cannot be extended

– Connection to PC via micro USB socket

– Integrated realtime clock

– Accommodates external IFS-CONFSTICK memory module

– A further eight channels can be configured with corresponding PLC-INTERFACE termi-

nal blocks as digital inputs or outputs

PLC-V8C stand-alone modules 2

– Stand-alone logic module with 16 I/Os, cannot be extended

– Connection to PC via micro USB socket

– Integrated realtime clock

– Accommodates external IFS-CONFSTICK memory module

– A further eight channels can be configured with corresponding PLC-INTERFACE termi-

nal blocks as digital or analog inputs or outputs

Order No. Designation

2905082 PLC-V8C/SC-24DC/SAM with screw connection

2905136 PLC-V8C/PT-24DC/SAM with Push-in connection

Order No. Designation

2907445 PLC-V8C/SC-24DC/SAM2 with screw connection

2907443 PLC-V8C/PT-24DC/SAM2 with Push-in connection
