Structure and dimensions
6452_en_11 Phoenix Contact 59 / 188
6.1.4 Basic structure of power-level terminals
(no longer in product range)
Power-level terminals are located in a power housing.
Figure 6-2 Basic structure of Inline housing for power-level terminals
The components required for marking are listed on the item page at
phoenixcontact.com/products
.
ZBFM: Zack marker sheets, flat
ZBFM labeling field
Release flap
Unlocking flap
Diagnostic and status
indicators
Potential routing for
low-level signals
Latching on
DIN rail
Feather of
keyway/featherkey connection
Slote for
brake module
Slot for motor
output connector
Slot for
incoming mains (400 V AC)
Slot for outgoing mains (400 V AC)
ZBFM
labeling field
Slot for hand-held
operator panel
Data jumpers
