IL SYS INST UM E

56 / 188 Phoenix Contact

6452_en_11

Grounding (FE) All Inline Block IO modules have an FE spring (metal clip) on the bottom of the electron-

ics base. This spring establishes an electrical connection to the DIN rail. Use grounding

terminals to connect the DIN rail to protective ground. The module is grounded when it is

snapped onto the DIN rail.

To ensure reliable functional grounding of the module even when the DIN rail is dirty or

the metal clip is damaged, Phoenix Contact also recommends grounding the module via

one of the FE terminal points of a power connector.

Shielding Shield connectors are available for connecting shielded cables.

Parameterization Some modules can be parameterized via process data or PCP. For detailed information,

please refer to the module-specific data sheet.

Data formats The measured values and the corresponding output values of analog modules can be rep-

resented in different data formats depending on the module used and its configuration.

These formats are listed in the relevant module-specific data sheets.

Diagnostics The scope of the diagnostics depends on the module used and is specified in the relevant

module-specific data sheet.

Additional documentation For more detailed information about the function, properties, wiring, and parame-

terization of the individual modules, please refer to the module-specific

documentation.
