Important information about voltage areas

6452_en_11 Phoenix Contact 17 / 188

4.2 Correct usage

Inline Block IO modules and Inline terminals should only be used according to the in-

structions in the terminal-specific data sheets and this user manual. Phoenix Contact ac-

cepts no liability if the device is used for anything other than its designated use.

When used in the SELV area:

NOTE: Disregarding this warning may result in malfunction

Do not replace terminals while the power is connected.

Before removing or mounting a terminal, disconnect power to the entire station.

Make sure the entire station is reassembled before switching the power back on.

When used in the low voltage area:

WARNING: Dangerous contact voltage

Do not replace terminals while the power is connected.

Before removing or mounting a terminal, disconnect power to the entire station.

Make sure the entire station is reassembled before switching the power back on.

WARNING: Dangerous contact voltage

Please note that there are dangerous contact voltages when switching circuits that

do meet SELV requirements.

When working on the terminals and wiring, always switch off the supply voltage and

ensure it cannot be switched on again.

4.3 Notes for Inline

4.3.1 Safety notes for use in the low voltage area

Only qualified personnel may work on Inline terminals outside the PELV area.

In terms of this manual, qualified personnel are persons who, because of their education,

experience, and instruction, and their knowledge of relevant standards, regulations, ac-

cident prevention, and service conditions, have been authorized to carry out any required

operations, and who are able to recognize and avoid any possible dangers.

The instructions given in the terminal-specific data sheets must be followed during

installation and startup.
