Configuration help for selecting the optimum analog input device for temperature recording

6452_en_11 Phoenix Contact 167 / 188

A 3.2 Inline Block IO (no longer in product range)

Table A-3 Configuration help for selecting Inline Block IO modules for temperature recording

Criterion ILB IB AI4 AO2 ILB PB AI4 AO2

2878777 2878874

RTD

detection

RTD detection

(Inputs for resistance temperature detectors,

e.g., Pt100, Pt1000, Ni100, Ni1000)

Yes Yes

Number of RTD 2-wire sensors 4 4

Number of RTD 3-wire sensors 4 4

Number of RTD 4-wire sensors 4 4

Dynamic

response

Dynamic response of measuring inputs Very high Very high

Measurements/second

(typical for all channels)

43 ... 192 43 ... 192

Precision Precision High Medium

Typical tolerance of Pt100 or TC (at T

A

= +25°C) ±0.3 K ±0.5 K

Maximum tolerance of Pt100 or TC (at T

A

= +25°C) ±1.6 K ±1.9 K
