Configuration help for selecting the optimum analog input device for temperature recording

6452_en_11 Phoenix Contact 165 / 188

A 3 Configuration help for selecting the optimum

analog input device for temperature recording

A 3.1 Inline

Table A-1 Configuration help for selecting Inline terminals for temperature recording (RTD)

Criterion IB IL TEMP 2

RTD-PAC

IB IL TEMP

4/8 RTD-PAC

IB IL TEMP

4/8 RTD/EF-

PAC

IB IL RTD

4/PT100-ECO

IB IL RTD

4/PT1000-

ECO

2861328 2863915 2897402 2702499 2702501

IB IL TEMP 2

RTD-XC-PAC

IB IL TEMP

4/8 RTD/EF-

XC PAC

2701217 2701218

(no longer in

product

range)

RTD

detection

RTD detection

(Inputs for resistance

temperature detec-

tors, e.g., Pt100,

Pt1000, Ni100,

Ni1000)

Yes Yes Yes Yes (Pt 100) Yes (Pt 1000)

Number of RTD 2-

wire sensors

2 8 8 4 4

Number of RTD 3-

wire sensors

2 8 8 – –

Number of RTD 4-

wire sensors

1 - 8 – –

Dynamic

response

Dynamic response of

measuring inputs

High Very high Low Medium Medium

Measurements/sec-

ond

(typical for all chan-

nels)

30 … 50 4 … 165 0.3 … 0.5 1.6 1.6

Precision Precision High Medium Very high Medium Medium

Typical tolerance of

Pt100 or TC

(at T

A

= +25°C)

±0.26 K ±0.50 K ±0.09 K ±0.8 K ±0.8 K

Maximum tolerance

of Pt100 or TC

(at T

A

= +25°C)

±1.0 K ±2.13 K ±0.19 K ±1.7 K ±1.7 K
