Connecting cables
6452_en_11 Phoenix Contact 139 / 188
12.5 Connecting sensors and actuators
Sensors and actuators are connected using connectors. The relevant terminal-specific
data sheet indicates which connector(s) can be used for which terminal.
Connect the unshielded cables as described in Section “Connecting unshielded cables”
on page 128.
Connect the shielded cables as described in Section “Connecting shielded cables using
an Inline shield connector” on page 129.
12.5.1 Connection methods for sensors and actuators
Most of the digital I/O terminals in the Inline product range support the connection of
sensors and actuators in 1, 2, 3 or 4-wire technology.
Because of the different types of connectors, a single connector can support the following
connection methods:
– 8 sensors or actuators in 1-wire technology
– 2 sensors or actuators in 2, 3 or 4-wire technology
– 4 sensors or actuators in 2 or 3-wire technology
– 2 sensors or actuators in 2 or 3-wire technology with shield
(for analog sensors or actuators)
When connecting analog devices, please refer to the terminal-specific data sheets,
as the connection method for analog devices differs from that for digital devices.
