IL SYS INST UM E

138 / 188 Phoenix Contact

6452_en_11

12.4 Connecting the bus

The bus cable for your system is connected directly to the module in the case of

Inline Block IO and to a bus coupler in the case of Inline. Table 12-4 below lists the basic

options for connecting the bus.

Key:

Connect the fieldbus according to the documentation for your Inline Block IO

module or Inline bus coupler.

Table 12-4 Connection options for the individual fieldbus systems

Fieldbus Connection method

(to the Inline Block IO module or

the Inline bus coupler)

Connection is

available

Inline Inline

Block IO

PROFINET RJ45 female connector Yes Yes*

SCRJ female connector Yes* No

INTERBUS Inline shield connector Yes Yes*

9-pos. D-SUB female connector/

9-pos. D-SUB male connector

Yes Yes*

F-SMA female connector Yes No

E2000 female connector Yes* No

PROFIBUS DP 9-pos. D-SUB female connector Yes Yes*

Ethernet/IP™ RJ45 female connector Yes No

Ethernet

TCP/IP

RJ45 female connector Yes Yes*

EtherCAT



RJ45 female connector Yes No

Modbus/TCP RJ45 female connector Yes Yes*

Modbus/RTU 9-pos. D-SUB female connector Yes No

Sercos II F-SMA female connector Yes* No

Sercos III RJ45 female connector Yes Yes*

DeviceNet™ 2 x 5-pos. TWIN-COMBICON male connectors Yes* Yes*

CANopen



2 x 5-pos. TWIN-COMBICON male connectors Yes No

9-pos. D-SUB female connector No Yes*

Mechatrolink USB type A Yes* No

Bluetooth Radio, antenna connection with SMA female

connector

No Yes*

Yes Connection method is available

No Connection method is not available or

no devices are available at present for this bus system

* No longer in product range
