Device management

4083_en_C PHOENIX CONTACT 33/46

5.5.3 Serial communication

Serial modules allow communication on RS-232/422/485 layers using Modbus

server/client or raw socket protocols.

The FL SWITCH EP7400-M8SERRJ uses an RJ45 connector and the FL SWITCH EP7400-

M4SERDB uses a D-Sub 9 connector to communicate with serial devices.

Table 5-7 FL SWITCH EP7400 -SERRJ pin assignment

RJ45 pin RS-232 RS-485 half-mode RS-422/485 full mode

1 –

2 –

3 GND GND GND

4 GND GND GND

5 RX RX+

6 TX TX+/RX+ TX+

7 CTS RX-

8 RTS TX+/RX+ TX-

Table 5-8 FL SWITCH EP7400 -SERDB pin assignment

RJ45 pin RS-232 RS-485 half-mode RS-422/485 full mode

1 – – –

2 RX – RX+

3 TX TX+/RX+ TX+

4 – – –

5 GND GND GND

6 GND GND GND

7 RTS TX-/RX- TX-

8 CTS – RX-

9 GND GND GND
