30/46 PHOENIX CONTACT

4083_en_C

5.3 RJ45 Ethernet pinout

With 10/100/1000BASE-T(X) cables, pins 1 and 2 are used for transmitting data, and pins

3 and 6 for receiving data.

The switch supports auto MDI/MDI-X operation. Use a cable to connect the switch to a

PC. The tables below show the 10Base-T/ 100Base-T(X) MDI and MDI-X and 1000 Base-

T MDI/MDI-X pin assignments. 10/100 Base-T(X) MDI/MDI-X pin assignments is as fol-

lows:

Table 5-3 RJ45 pinout for 10/100 Base-T(X)

RJ45 pin Assignment

1 TD+

2 TD-

3 RD+

4 Not used

5 Not used

6 RD-

7 Not used

8 Not used

Table 5-4 RJ45 pinout for 1000 Base-T(X)

RJ45 pin Assignment

1 BI_DA+

2 BI_DA-

3 BI_DB+

4 BI_DC+

5 BI_DC-

6 BI_DB-

7 BI_DD+

8 BI_DD-

Table 5-5 10/100 Base-TX MDI port MDI-X port

RJ45 pin Assignment

1 TD+ (transmit) RD+ (receive)

2 TD- (transmit) RD- (receive)

3 RD+ (receive) TC+ (transmit

4 Not used

5 Not used

6 RD- (receive) TD- (transmit)

7 Not used

8 Not used
