Device management

4083_en_C PHOENIX CONTACT 29/46

5 Device management

5.1 Serial console

Connect a PC or terminal directly to the serial console to access the boot-time control and

FL SWITCH EP7… interfaces. The serial console port provides access to the console inter-

face. The serial console port is of a industry standard format of RS-232 using an RJ45

connector. The RS-232 default setup parameters are 115200 bps, 8, N.

For connection to existing older laptop computers, an RJ45 to D-SUB9 cable is provided.

For newer laptops, the user may purchase an RJ45 to USB cable.

The serial console is intended to be used only as a temporary connection during initial

configuration or troubleshooting.

5.2 Ethernet ports and communication cabling

The FL SWITCH EP7… comes with standard Ethernet ports. According to the link type, the

switch uses CAT 3, 4, 5, and 5e UTP cables to connect to any other network devices (com-

puters, servers, switches, routers, or hubs).

Table 5-1 RJ45 to RS-232 pinout

RJ45 pin RS-232 function

1 RTS

3 TX

4 GND

5 GND

6 RX

8 CTS

Table 5-2 Ethernet cable types

Cable Type Length, max Description

10Base-T Cat. 3, 4, 5, 100 Ω UTP 100 m (328 ft.) RJ45

100Base-T Cat. 5, 100 Ω UTP UTP 100 m (328 ft.) RJ45

1000Base-T Cat. 5/5e, 100 Ω

UTP

UTP 100 m (328 ft.) RJ45
