Description of the FL PN/PN SDIO-2TX/2TX

8220_en_06 PHOENIX CONTACT 27

2.4 Mapping process data to PROFINET IO

Following integration in an engineering tool, the safe PROFINET gateway uses the following

process data in both connected PROFINET systems:

Slot assignment/

process data

Bit assignment of

diagnostics slot 1

For more detailed information on the diagnostics of the safe PROFINET gateway, please

refer to “Bit assignment of diagnostics slot 1” on page 52 and “PROFINET diagnostic

messages/alarms” on page 57.

Table 2-1 Slot assignment/process data of the safe PROFINET gateway in both connected PROFINET systems

Slot Ty pe Description PROFINET IO user data length

Fixed-in

PROFINET functions with

PDev

–

Process data:

Status/diagnostics

2 bytes of inputs

Optional

Process data:

Standard I/Os

2 bytes of inputs/2 bytes of outputs

4 bytes of inputs/4 bytes of outputs

8 bytes of inputs/8 bytes of outputs

16 bytes of inputs/16 bytes of outputs

Default 32 bytes of inputs/32 bytes of outputs

Optional

64 bytes of inputs/64 bytes of outputs

128 bytes of inputs/128 bytes of outputs

Optional Slot 2 is empty –

Default

Process data:

PROFIsafe messages

7 bytes of inputs/6 bytes of outputs; 3 bytes of which are safe

inputs (2 bytes of which can be used) and 2 bytes of safe out-

puts for coupling safe process data.

Optional

12 bytes of inputs/11 bytes of outputs; 8 bytes of which are

safe inputs (7 bytes of which can be used) and 7 bytes of safe

outputs for coupling safe process data.

16 bytes of inputs/15 bytes of outputs; 12 bytes of which are

safe inputs (11 bytes of which can be used) and 11 bytes of

safe outputs for coupling safe process data.

Slot 3 is empty –

You have the option of changing the amount of process data for standard I/Os for slot 2.

As an option, you can parameterize an empty/unused slot for slot 2.

You have the option of changing the amount of process data for PROFIsafe messages for

slot 3.
