FL PN/PN SDIO-2TX/2TX

PHOENIX CONTACT 8220_en_06

1.7 Intended use

The FL PN/PN SDIO-2TX/2TX safe PROFINET gateway is designed exclusively for use in

PROFINET/PROFIsafe systems. It connects PROFINET systems in different subnetworks

together to exchange safety-related and non-safety-related I/O data between the systems.

The FL PN/PN SDIO-2TX/2TX can only perform its safety-related tasks in a PROFIsafe

system if the device has been integrated into the execution process correctly and in such a

way as to avoid errors.

You must observe all information in this manual as well as in the documents listed in

“Documentation” on page 17. In particular, only use the device according to the technical

data and ambient conditions specified in Section 7, “Technical data and ordering data” on

page 61 and onwards.

Within a PROFIsafe system, the FL PN/PN SDIO-2TX/2TX can be used to achieve safety

functions with the following requirements depending on the conditions of use:

– Up to SIL 3 according to standard EN 61508

– Up to SIL CL 3 according to standard EN 62061

– Up to PL e/Cat. 4 according to standard EN ISO 13849-1

Degree of protection

Assembly guidelines During installation of the device, observe the instructions in Section 3, “Mounting, removal,

electrical installation, and replacement”.

WARNING: Observe the intended use

Only use the FL PN/PN SDIO-2TX/2TX safe PROFINET gateway in accordance with the

instructions in this section.

Please also refer to “Achievable safety depending on the modules used” on page 14.

NOTE:

Only mount the device on DIN rails according to DIN EN 60715.

Degree of protection of the device when mounted: IP20.

To ensure correct operation, the device mounted on a DIN rail must be installed in housing

or a control cabinet with a minimum of IP54 protection or higher.
