Starting up the ERS 1000
110265_en_02 PHOENIX CONTACT 13 / 80
3.1.2 Copying the template for the switch
Copy the supplied template “ERS1000.ntpl” from the “$NIAGARA$/extra” directory to your
personal user directory “$NIAGARA$/Workbench User Home/templates”.
“Workbench User Home” is a link to the personal Niagara directory. This results in the path
“$UserDirectory$/Niagara4.8/PhoenixContact/shared”, for example.
3.1.3 Copying the firmware file
Copy the desired firmware file “ERS1000_*.uLuxRes” from the “$NIAGARA$/extra” direc-
tory into the “Files” folder of your Emalytics or Niagara station (ILC 2050 BI). To do this, use
the drag-and-drop function in Workbench.
Figure 3-3 “Files” directory of the Emalytics Station in Workbench
3.1.4 Embedding the driver in Emalytics (Niagara)
Figure 3-4 Double-click on “Config/Drivers”.
Figure 3-5 Select “New” in the bottom “Drivers” menu, and select and add the “Emalyt-
ics Room Switch Network” type.
