Device overview

111433_en_00 Phoenix Contact 9 / 78

2 Device overview

2.1 Short description

The ECM-UC current measuring transducers are high-precision measuring devices for

universal use that simultaneously measure all AC, DC, and RMS components and convert

them into analog standard signals or digital signals. Currents are measured using the

principle of true RMS value measurement (TRMS). The output signal is proportional to the

input variable. The analog output is short-circuit-proof.

2.2 Overview of interfaces

Table 2-1 Overview of interfaces

Interfaces ...-10A-... ...-100A-...

Analog output ECM-UC-10A-UI

(1136504)

ECM-UC-100A-UI

(1136513)

Analog output,

digital input,

digital transistor output,

digital relay output

ECM-UC-10A-UI-REL

(1698164)

ECM-UC-100A-UI-REL

(1698172)

Modbus/RTU ECM-UC-10A-MRTU

(1191969)

ECM-UC-100A-MRTU

(1191986)

Modbus/TCP, Ethernet ECM-UC-10A-MTCP

(1191970)

ECM-UC-100A-MTCP

(1191984)
