ECM – multifunctional current measuring transducers
16 / 78 Phoenix Contact
111433_en_00
3.2 Mounting and removal
Snap the device onto a 35 mm DIN rail in the control cabinet in accordance with
EN 50022.
To release, pull the metal lock downwards and then lift the device upwards from the DIN rail.
Figure 3-1 Mounting and removal
3.3 General block diagram
Figure 3-2 General block diagram
