Error codes
8663_en_08 Phoenix Contact 25 / 38
3.2 Error codes for bus diagnostics
Table 3-2 Error codes for bus diagnostics
Code
(hex)
Additional code Meaning Remedy
0BD1 The bus could not be activated successfully due to
malfunctions on the bus.
Check the bus configuration.
0BF1
0BF2
0BF3
0C01 Device number The configured module cannot be reached.
A device present in the configuration frame has been
removed from the physical bus structure after the con-
figuration frame was connected.
Check the configuration.
Adapt the configuration
frame if the change was
made on purpose.
0C02 An unconfigured module has been detected.
An additional device was added at the end of the phys-
ical bus structure after the configuration frame was
connected.
0C11 The module is not located in the configured slot.
An active device was placed elsewhere in the physical
bus structure after the configuration frame was con-
nected.
0C12 The module can be reached, but was not started up
due to missing parameters.
An active device was replaced by an unknown device in
the physical bus structure after the configuration
frame was connected (wrong instance ID).
0C13 The process data length does not correspond to the
configured value.
The process data width of an active device was
changed after the configuration frame was connected.
0C14 The module type does not correspond to the config-
ured value.
0C15
0C16 An address conflict has occurred. Restart the station.
