Error codes
8663_en_08 Phoenix Contact 21 / 38
0939 Variable_ID not enabled The variable ID is not enabled. (Password protection) Check the invocation.
093A Incorrect Variable_ID Length specification in the variable ID is 0 or incorrect. Check the invocation.
093B Incorrect Variable_Count The number of variables has been calculated incor-
rectly.
Check the invocation.
0A01 A hardware fault or firmware error has occurred. Restart the device. If the
problem persists, please
contact Phoenix Contact.
0A02 Current state of the local
bus master
A service was invoked that is not permitted in the cur-
rent status of the local bus master.
Possible states:
0001 Ready
(After restart or reset)
0002 Load config
(Configuration cannot be loaded)
0004 Config ready
(Configuration loaded successfully)
0008 Active
(Configuration frame connected)
0010
Param ready
(Parameterization of modules completed)
0020
Run
(Process data traffic running)
0080 Force mode
(Startup tool specifies outputs)
0100 Ready fail
(Communication breakdown in Ready)
0800 Active fail
(Communication breakdown in Active)
1000 Param ready fail
(Communication breakdown in Param Ready)
2000 Run fail
(Process data traffic with subsystem)
4000 Force fail
(Application timeout for all devices)
8000 Force Mode Fail
(Communication breakdown in force mode)
Set the local bus master
to the required state.
0A03 Memory problem (e.g., buffer too small) Restart the device. If the
problem persists, please
contact Phoenix Contact.
0A04 Inconsistent parameters. Check the invocation.
0A05 Invalid parameters. Check the invocation.
0A06 Access not supported. Check the invocation.
Table 3-1 Error codes for user errors [...]
Code
(hex)
Additional code Meaning Remedy
