Diagnostics in the Axioline F system
8663_en_08 Phoenix Contact 11 / 38
2.2 Diagnostics via object 0018
hex
(DiagState)
In addition, each I/O module features object 0018
hex
(DiagState), which is used for the
structured reporting of an error. The I/O module also provides its diagnostic state in this
way.
The object is illustrated in the module-specific documentation of each I/O module.
Table 2-4 Diagnostic state (read) according to basic profile V2.x
Index
[hex]
Object name Data type Length in
bytes
Meaning
0018 DiagState Record Diagnostic
state
Complete diagnostic information
.1 Consecutive
no.
UINT16 2 Error num-
ber
0 ...
65535
dec
Unique, consecutive error number
since the last power up or reset of
the diagnostic counter
.2 Priority UINT8 1 Priority Priority of the message. 1: Highest priority
See Table 2-7 on page 13
00
hex
No malfunction
01
hex
Error
02
hex
Warning
03
hex
Information
81
hex
Error removed
82
hex
Warning removed
83
hex
Information removed
.3 Channel/
Group/
Module
UINT8 1 Channel/
group/
module
Channel, group or module where the malfunc-
tion occurred.
Additional information available under “Addi-
tional information”.
00
hex
No malfunction
xx
hex
Channel xx, group xx or module xx
FF
hex
Entire device
.4 Code Octet string 2 Error code
.5 MoreFollows Bit string 8 1 Additional
information
Further information about the malfunction
00
hex
Subindex 3 = channel number
04
hex
Subindex 3 = group number
08
hex
Subindex 3 = module number
Other Not used at present.
.6 Text Visible string Max. 51 Text Plain text message. Default: Status OK
