clipx WIRE assist
32 / 50 Phoenix Contact
109435_en_02
Control device 1193694 1194550 1330670 1365645 1365647 1365648 1385765
Input voltage
230 V AC /
50 Hz
120 V AC /
60 Hz
230 V AC /
50 Hz
230 V AC /
50 Hz
230 V AC /
50 Hz
230 V AC /
50 Hz
230 V AC /
50 Hz
Input power 300 W 300 W 300 W 300 W 300 W 300 W 300 W
Output voltage
12 V DC ...
40 V DC
12 V DC ...
40 V DC
12 V DC ...
40 V DC
12 V DC ...
40 V DC
12 V DC ...
40 V DC
12 V DC ...
40 V DC
12 V DC ...
40 V DC
Operating time at maximum nomi-
nal load
10% ā¼2 min continuous operation, followed by an 18 min break
Limits of additionally attached holders and devices
Maximum load-carrying capacity of both supporting arms
(per arm)
45 kg
Maximum extension length of the four holders on the side of
the workbench (per holder)
140 mm ... 300 mm
Maximum extension length of both vertical tube connections
of the support arm (per tube)
30 mm ... 350 mm
Limits due to the current car-
rying capacity of the addi-
tional devices
1193694 1194550 1330670 1365645 1365647 1365648 1385765
Maximum current carrying ca-
pacity due to the connected de-
vices
16 A 15 A 13 A 16 A 16 A 20 A 10 A
Socket strip
AS-WB-F/POWER STRIP 5...
1193789 1194556
...US
1193791
...230-G
1193792
...230-E
1193794
...230-L
1365651
...230-I
1385771
...230-AI
Voltage 250 V 120 V 250 V 250 V 250 V 240 V 250 V
Current 16 A 15 A 13 A 16 A 16 A 20 A 10 A
Power consumption 3500 W 1800 W 3000 W 3500 W 3500 W ā 2500 W
Approval CE cCSAus UKCA,
CE
CE CE CE CCC
