Technical appendix
109435_en_02 Phoenix Contact 31 / 50
A Technical appendix
A 1 Technical data
Workbench 1193694 1194550 1330670 1365645 1365647 1365648 1385765
Voltage
230 V 120 V 230 V 230 V 230 V 230 V 230 V
Current 16 A 15 A 13 A 16 A 16 A 20 A 10 A
Frequency
50 Hz 60 Hz 50 Hz 50 Hz 50 Hz 50 Hz 50 Hz
Workbench
Maximum load 500 kg
Maximum load for the work surface 65 kg
Overvoltage category 2
Dimensions and weight
Width x height x depth (when not extended) 900 mm x 810 mm x 781 mm
Width x height x depth (when extended) 900 mm x 1350 mm x 781 mm
Weight 95 kg
Ambient conditions
Room temperature +10°C ... +40°C
Relative humidity 20% ... 80% at 30°C
Air pressure 700 hPa ... 1060 hPa
Operating altitude 2000 m UELN, maximum
Pollution degree 2
Lift drive
Nominal voltage 18 V DC
Current consumption at nominal load 10 A DC, maximum
Permissible pressure load 800 N, maximum
Operating time at maximum nominal load
10% ∼2 min continuous operation, followed by an 18 min break
Lift <650 mm
Rate of movement 38 mm/s, approximately (depending on version)
Noise level 55 dB(A)
