Copyright © 2020, Fast ČR, a. s. Revision 10/2022
EN - 8
Electrical connection
WARNING!
Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a
transformer of 110/220 V and 3000 W between the electrical connection.
Connect the product to a grounded outlet protected by a fuse complying with the values in
the “Technical Specications” table”.
The earthed plug of the machine must be connected to an earthed outlet supplied by suitable
voltage and current.
In the absence of earthing installation, an authorised electrician should carry out an earthing
installation. In the case of use without earthing installed, we will not be responsible for any loss
of use that may occur.
The plug on this appliance may incorporate 13A fuse depending on the target country.
(For Example UK, Saudi Arabia)
Fitting the machine undercounter
If you wish to t your machine undercounter, there must be sucient space to do so and the wiring-
plumbing must be suitable to do so (1). If the space under the countertop is suitable for tting your machine,
remove the worktop as shown in the illustration (2).
WARNING!
The countertop, of which the machine will be placed under, must be stable in order to prevent imbalance.
The top panel of the dishwasher must be removed to t the machine under the countertop.
To remove the top panel, remove the screws that hold it on, located at the rear of the machine. Then, push
the panel 1 cm from the front towards the rear and lift it. Adjust the machine feet according to the slope of
the oor (3).
Fit your machine by pushing it under the counter taking care not to crush or bend the hoses (4).
WARNING!
After removing the top panel of your dishwasher, the machine should be placed in a space of the
dimensions shown in the gure below.
