Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice

4

PERLICK MOBILE BARS

Operation/Installation Manual

MOBS-42TSMOBS-66TS MOBS-66TS-S

MODEL NOS. MOBS-42TS MOBS-66TS MOBS-66TS-S

DIMENSIONS:

EXTERIOR mm

Length 46-1/4" ( 1175) 70-1/8" (1785) 70-1/8" (1785)

Width 32-3/16" (819) 32-3/16" (819) 32-3/16" (819)

Height 46-5/16" (1176) 46-5/16" (1176) 46-5/16" (1176)

Weight (lbs) 236 lbs. (107 kg) 339 lbs. (154 kg) 370 lbs. (168 kg)

DIMENSIONS:

SHIPPING mm

Length 60” (1524) 75” (1905) 75” (1905)

Width 40” (1016) 40” (1016) 40” (1016)

Height 70” (1778) 70” (1778) 70” (1778)

Weight (lbs) 316 lbs. (143 kg) 439 lbs. (199 kg) 470 lbs. (213 kg)

PERLICK BAR EQUIPMENT Ice Chest TS30IC with sliding cover TS30IC with sliding cover TS30IC with sliding cover

Insulated Bottle Well TS12U TS12U TS12U

Drainboard N/A TS12 (2 ea.) TS12 (1 ea.)

Hand Sink N/A N/A TS12HSN with side splash

Speed Rail SR-S42A (1 ea.)

SR-S42A (1 ea.)

SR-S12A (2 ea.)

SR-S42A (1 ea.)

SR-S12A (2 ea.)

ELECTRICAL Voltage 120V AC 120V AC 120V AC

Frequency 60 Hz 60 Hz 60 Hz

Phase Single Single Single

Amperage 0.3 A 0.4 A 13.3 A

Connection NEMA 5-15P NEMA 5-15P NEMA 5-15P

Cord Length 12ft 12ft 12ft

LED BARTENDER TASK LIGHTING Color Temperature 4000K 4000K 4000K

Lumen Output 800 LM 1200 LM 1200 LM

WATER HEATER Temperature Range N/A N/A 50°F - 140°F

Tank Volume N/A N/A 1.5 gal

Recovery time @ 60°^ N/A N/A 8 minutes

WATER PUMP Max Flow N/A N/A 3 GPM (11.3 LPM)

Switch O Pressure N/A N/A 45 PSI (3.1 bar)

GRAY WATER/ICE MELT TANK PREPLUMBED Capacity 5 gal (18.9 L) 5 gal (18.9 L) 6 gal (22.7 L)

POTABLE WATER TANK PREPLUMBED Capacity N/A N/A 5 gal (18.9 L)
