Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice

3

Form No. Z2654

Rev. 04.21.21

PERLICK MOBILE BARS

Operation/Installation Manual

MOBS-42TE

MOBS-66TE

MOBS-66TE-S

MODEL NOS. MOBS-42TE MOBS-66TE MOBS-66TE-S

DIMENSIONS:

EXTERIOR mm

Length 46-1/4" ( 1175) 70-1/8" (1785) 70-1/8" (1785)

Width 35-9/16" (903) 35-9/16" (903) 35-9/16" (903)

Height 46-5/16" (1176) 46-5/16" (1176) 46-5/16" (1176)

Weight (lbs) 239 lbs. (108 kg) 351 lbs. (159 kg) 380 lbs. (172 kg)

DIMENSIONS:

SHIPPING mm

Length 60” (1524) 75” (1905) 75” (1905)

Width 40” (1016) 40” (1016) 40” (1016)

Height 70” (1778) 70” (1778) 70” (1778)

Weight (lbs) 319 lbs. (145 kg) 451 lbs. (205 kg) 480 lbs. (218 kg)

PERLICK BAR EQUIPMENT Ice Chest TS30IC with sliding Cover TS30IC with sliding Cover TS30IC with sliding Cover

Insulated Bottle Well TSC12IBW TSC12IBW TSC12IBW

Drainboard N/A TSCS12 (2 ea.) TSCS12 (1 ea.)

Hand Sink N/A N/A TS12HSN with side splash

Speed Rail

SRC-CL left curved (1 ea.)

SRC-CR right curved (1 ea.)

SRC-S18 18” straight (1 ea.)

SRC-CL left curved (1 ea.)

SRC-CR right curved (1 ea.)

SRC-S18 18” straight (1 ea.)

SRC-CL left curved (1 ea.)

SRC-CR right curved (1 ea.)

SRC-S18 18” straight (1 ea.)

ELECTRICAL Voltage 120V AC 120V AC 120V AC

Frequency 60 Hz 60 Hz 60 Hz

Phase Single Single Single

Amperage 0.3 A 0.4 A 13.3 A

Connection NEMA 5-15P NEMA 5-15P NEMA 5-15P

Cord Length 12ft 12ft 12ft

LED BARTENDER TASK LIGHTING Color Temperature 4000K 4000K 4000K

Lumen Output 800 LM 1200 LM 1200 LM

WATER HEATER Temperature Range N/A N/A 50°F - 140°F (10°C - 60°C)

Tank Volume N/A N/A 1.5 gal (5.7 L)

Recovery time @ 60°^ N/A N/A 8 minutes

WATER PUMP Max Flow N/A N/A 3 GPM (11.3 LPM)

Switch O Pressure N/A N/A 45 PSI (3.1 bar)

GRAY WATER/ICE MELT TANK PREPLUMBED Capacity 5 gal (18.9 L) 5 gal (18.9 L) 6 gal (22.7 L)

POTABLE WATER TANK PREPLUMBED Capacity N/A N/A 5 gal (18.9 L)
