14
INSTALLATION INSTRUCTIONS
(Continued)
WINDOW REQUIREMENTS
Your air conditioner is designed to install in
standard double hung windows with opening
widths of 23 to 36 inches (584mm to 914mm)
and a minimum height of 16.5 inches (419 mm).
CAUTION
• Do not, under any circumstances, cut
or remove the third (ground) prong from
the power cord.
• Do not change the plug on the
power cord of the air conditioner.
Aluminum house wiring may present
special problems- consult a qualied
electrician. When handling unit, be
careful to avoid cuts from sharp metal
edges and aluminum ns on front and
rear coils.
• The rear of the unit must be outdoors,
not inside a building or garage.
Safety Lock and 5/8in Screws
Top Rail and 3/8in Screws
Frame Assembly (Left)
Safety Lock and 5/8in Screw
Frame Assembly (Right)
Air Conditioner unit
Window Sash Seal Foam
Remote control
INSTALLATION OVERVIEW
RIGHT
LEFT
IMPORTANT NOTICE:
WARRANTY VOID
FOR IMPROPER INSTALLATION
Please note that the warranty for the window
air conditioner will be void if it is installed in
a wall sleeve or any other type of enclosure
that interferes with any air vents. Failure of
proper installation will lead to damage or
malfunctioning of the unit.
For detailed instructions on the correct installation
process, please refer to the 'Installation' section
of this user manual. Following these guidelines will
help guarantee optimal performance and protect
your warranty coverage.
16.5in (419mm)
