15
INSTALLATION INSTRUCTIONS
4. WINDOW INSTALLATION
Hung Window Installation
Step 1 Insert the window slider assembly into
the window opening.
Step 2 Cut the non-adhesive foam seal C strip
to match the width of the window. Insert the
seal between the glass and the window frame to
prevent air and insects from getting into the room
Step 3 If desired, install the security bracket
with 2 screws as shown.
3. COMPLETE SEALING OF WINDOW
Cut the adhesive foam seal A and B strips to the
proper lengths, and attach them to the window
sash and frame as shown.
Hung Window Installation
Sliding Window Installation
(Continued)
Foam Seal A
(Adhesive type)
Foam Seal B
(Adhesive type - shorter)
Foam Seal B
(Adhesive type - shorter)
Foam Seal A
(Adhesive type)
