5

Please read ALL instructions before installing. It is

recommended that two people install this product.

0MHUL^LSLJ[YPJHSV\[SL[PZYLX\PYLKOH]L[OLV\[SL[

PUZ[HSSLKI`HX\HSPÄLKLSLJ[YPJPHUILMVYLPUZ[HSSPUN[OL

air conditioning unit.

Window Sash Seal

Top Angle

Foam Gasket

Side Retainer

Locknut

Safety Lock and

3/4 (or 1/2)

Long Hex Head Screw

1/2 Long

Screw and

Locknuts

Washer Head

Locking Screw

Seal Bottom

Rail to Unit

Frame

Assembly

(Left)

Frame Assembly

(Right)

3/4 Long

Flat Head

Bolt

Sill Angle

Bracket

Window Support

Bracket

FIG. A

SASH

SASH

19 MIN.

19 MIN.

1/2 MIN.

1/2 MIN.

1/2 MIN.

Board

thickness

as required

along entire

stool. Fasten

with 2 Nails

or Screws.

Storm window

frame or other

obstruction

Storm window

frame or other

obstruction

FIG. B FIG. C

PRELIMINARY INSTRUCTIONS

Do the following before installing the unit. (See

illustrations on left.)

*OLJRKPTLUZPVUZVM`V\Y\UP[[VKL[LYTPULWYVWLY

window dimensions:

Unit Height: 17

5

8 or 18

5

8

Unit Width: 23

5

8 or 26

1

2

Min. Window Height: 18

1

2 or 19

1

2

Min. Window Width: 28 or 31

Max. Window Width: 40

1

2 or 42

1. CHECK WINDOW OPENING SIZE — The mounting parts

furnished with this air conditioner are made to install

in a wooden sill, double-hung window. The standard

WHY[ZHYLMVY^PUKV^KPTLUZPVUZSPZ[LKHIV]L6WLU

sash to a minimum of 19 in. (483 mm). See Fig. B .

2. CHECK CONDITION OF WINDOW — All wood parts of

^PUKV^4<:;ILPUNVVKZOHWLHUKHISL[VÄYTS`

OVSK[OLULLKLKZJYL^Z0MUV[THRLYLWHPYZILMVYL

installing unit.

3. CHECK YOUR STORM WINDOWS — If your storm

^PUKV^MYHTLKVLZUV[HSSV^[OLJSLHYHUJLYLX\PYLK

correct by adding a piece of wood, as shown in

Fig. C, or by removing storm window while room air

conditioner is being installed.

4. CHECK FOR ANYTHING THAT COULD BLOCK AIRFLOW —

*OLJRHYLHV\[ZPKLVM^PUKV^MVY[OPUNZZ\JOHZ

shrubs, trees, or awnings. Inside, be sure furniture,

KYHWLZVYISPUKZ^PSSUV[Z[VWWYVWLYHPYÅV^

5. CHECK THE AVAILABLE ELECTRICAL SERVICE — Power

supply MUST be the same as that shown on the

unit serial nameplate. Power cord is 48 inches long.

)LZ\YL`V\OH]LHUV\[SL[ULHY+656;\ZLHU

extension cord.

6. CAREFULLY UNPACK THE AIR CONDITIONER — Remove

HSSWHJRHNPUNTH[LYPHS*V]LY[OLÅVVYK\YPUN

installation to prevent damage. Two people should be

used to move and install unit.
