9
([[HJO[OL[VWHUNSL[V^PUKV^MYHTL!<ZLH
drill bit to drill one hole through the hole in the
middle of top angle into the window frame, and
KYP]LVULVY/,?/,(+SVJRPUNZJYL^
through hole in the middle of top angle into the
window frame, as shown (Fig. 17B).
3/4 (or 1/2) long
hex head screw
FIG. 17B
STEP 7:
ATTACH ACCORDION PANELS TO
WINDOW FRAME
1. Extend the accordion panels out against the
window frame.
<ZLKYPSSIP[[VKYPSSHZ[HY[LYOVSL[OYV\NO[OL
OVSLPU[OL[VWSLNVMLHJO^PUKV^ÄSSLYWHULSHUK
into the window sash. (Fig. 18A and Fig. 18B.)
*VUULJ[^P[OVULVYSVUNOL_
head screw.
A. 3/4 (or 1/2)
long hex head
screw
B. Left-hand
Window Filler
Panel Top Leg
C. Window channel
A. 3/4 (or 1/2)
long hex head
screw
A
A
B
C
Window Sash
Weather Seals
FIG. 18A
FIG. 18B
STEP 8:
INSTALL WINDOW SASH SEAL AND
SAFETY LOCK
;YPTZHZOZLHS[VÄ[^PUKV^^PK[O0UZLY[PU[V
space between upper and lower sashes. (Fig 19A)
Window Sash Seal
FIG. 19A
([[HJOYPNO[HUNSLZHML[`SVJR-PN )
FIG. 19B
Safety Lock
3/4 (or 1/2)
long hex head
screw
STEP 9:
INSTALL CHASSIS INTO CABINET
AND INSTALL FRONT TO UNIT
1. Lift air conditioner and carefully slide into cabinet,
leaving 6 inches protruding.
+656;W\ZOVUJVU[YVSZVYÄUULKJVPSZ
)LZ\YLJOHZZPZPZÄYTS`ZLH[LK[V^HYKZYLHYVM
cabinet.
4. Installation of front is the reverse of removal
outlined in Step 1.
