EN 28
The table below shows the available settings.
Menu code Discription Configuration value
U2 Volume key sound 1 - 9 (default: 9, maximum)
U3 Volume for audio signal 1 - 9 (default: 9, maximum)
U4 Brightness of display 0 - 9 (default: 0, brightest)
U5 Timer animation 0: Timer animation off
1: Timer animation on (default)
U6 Automatic pan detection 0: Automatic pan detection off
1: Automatic pan detection on (default)
U7 Length of audio signal 0: during 120 sec. (default)
1: during 10 sec.
2: no audio signal
U9 Connection with a cooker hood
See text below
0: no connection (default)
1: connection with a cooker hood
Connection with a cooker hood
ATTENTION
First put the extractor hood in pairing mode (see the cooker hood manual for this),
then the hob.
Follow steps 1 to 4 from the previous page.
5.
Touch the cooking zone key on the rear left and choose number 9 by touching the slide
control.
▷ “U” will now flash alternately with number 9 on the display of the rear left cooking zone
for two minutes.
6.
Touch the cooking zone key on the front left and select number 1
.
▷ The hob will now search for the extractor hood; this takes a maximum of two minutes.
7. The extractor hood shows the confirmation whether the pairing was successful.
8. Finally, touch the on/off key
until you hear an audio signal,
to end the pairing mode on the
hob.
9. Check whether the connection was successful by switching the hob on again. If the lighting of
the extractor hood switches on, the connection has been successful.
USER MENU
