Pelco, Inc.

625 W. Alluvial, Fresno, California 93711 United States

USA & Canada Tel (800) 289-9100 Fax (800) 289-9150

International Tel +1 (559) 292-1981 Fax +1 (559) 348-1120

www.pelco.com

TECHNICAL SPECIFICATIONS

SYSTEM MODEL NUMBERS*

*System options contain a back box/mount, camera, and clear dome.

CERTIFICATIONS*

• CE - EN 55032 (Class A), EN 50130-4, EN 60950-1

• FCC (Class A) - 47 CFR Part 15

• UL and cUL Listed - UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07

• UL/IEC/EN 60950-22 (environmental models only)

• ICES-003 (Class A)

•RCM

•KCC

•NOM

•EAC

•BIS

• Type 4X (environmental models only) when installed properly with

IMP3EBAP

• IP66/67 (environmental models only) when installed properly

• IEC 60068:2-6 and 2-27

• ONVIF Profile S, Profile G, Profile Q, and Profile T conformant

*At the time of this publication, certifications are pending. Consult the

factory or www.pelco.com for the current status of certifications.

RECOMMENDED MOUNTS

WMVE-SW Wall mount arm, 1.5 in. NPT

PA101 with WMVE-SW Pole Mount

IMP3PMB-1I Wall mount

IMP3ICM-1E In-ceiling mount

IMP3PM-1E Pendant mount

IMM-CM with WMVE-SW

and IMP3PM-1E Corner mount

OPTIONAL ACCESSORIES

IMP3EBAP 4S electrical box adapter

IMP3LD-0E Smoked environmental lower dome

IMP3LD-0I Smoked indoor lower dome

IMP3LD-1E Clear environmental lower dome

IMP3LD-1I Clear indoor lower dome

Back Box Resolution Lens Model Number Description

Surface

1 MP 2.8 to 12 mm IMP131-1ERS Sarix Pro Environmental IR Dome

1 MP 2.8 to 12 mm IMP131-1IRS Sarix Pro Indoor IR Dome with Microphone

2 MP 2.8 to 12 mm IMP231-1ES Sarix Pro Environmental Dome

2 MP 2.8 to 12 mm IMP231-1ERS Sarix Pro Environmental IR Dome

2 MP 2.8 to 12 mm IMP231-1IS Sarix Pro Indoor Dome with Microphone

2 MP 2.8 to 12 mm IMP231-1IRS Sarix Pro Indoor IR Dome with Microphone

3 MP 2.8 to 12 mm IMP331-1ES Sarix Pro Environmental Dome

3 MP 2.8 to 12 mm IMP331-1ERS Sarix Pro Environment IR Dome

3 MP 2.8 to 12 mm IMP331-1IS Sarix Pro Indoor Dome with Microphone

3 MP 2.8 to 12 mm IMP331-1IRS Sarix Pro Indoor IR Dome with Microphone

5 MP 2.8 to 12 mm IMP531-1ES Sarix Pro Environmental Dome

5 MP 2.8 to 12 mm IMP531-1ERS Sarix Pro Environmental IR Dome

5 MP 2.8 to 12 mm IMP531-1IS Sarix Pro Indoor Dome with Microphone

5 MP 2.8 to 12 mm IMP531-1IRS Sarix Pro Indoor IR Dome with Microphone

Pelco, the Pelco logo, and other trademarks associated with Pelco products referred

to in this publication are trademarks of Pelco, Inc. or its affiliates. ONVIF and the

ONVIF logo are trademarks of ONVIF Inc. All other product names and

services are the property of their respective companies.

Product specifications and availability are subject to change without notice.

©Copyright 20120 Pelco, Inc. All rights reserved.

M4

Ø 0.43

(0.17)

Ø .43

(0.17)

M4

M3

0.5

(0.20)

Ø 0.63

(0.25)

Ø 0.45

(0.18)

Ø 0.45

(0.18)

10.70

(4.21)

10.70

(4.21)

4.29

(1.69)

4.15

(1.63)

4.15

(1.63)

4.29

(1.69)

4.15

(1.63)

4.29

(1.69)

4.59

(1.81)

4.29

(1.69)

4.15

(1.63)

2.30

(0.91)

2.30

(0.91)

2.30

(0.91)

2.30

(0.91)

1.52

(0.60)

1.92

(0.76)

4.29

(1.69)

4.29

(1.69)

4.29

(1.69)

4.29

(1.69)

4.29

(1.69)

4.38

(1.72)

4.38

(1.72)

4.38

(1.72)

IMP3EBAP 4S ELECTRICAL BOX ADAPTER

Color: RAL 9003
