TECHNICAL SPECIFICATIONS

ELECTRICAL

Network Port RJ-45 connector for 10/100Base-TX

Power Input IEEE802.3af PoE (Indoor), IEEE802.3at

(Environmental)

18 ~ 32 VAC,

12 ± 10% VDC

Indoor Dome

Environmental Dome

Local Storage Micro SDHC and SDXC card, 2 TB

addressable, 128 GB or more testable

Alarm

Input 1, PhotoMOS

™

relay (30 V, 1 A)

Output 1, PhotoMOS

™

relay (30 V, 1 A)

Triggers Unsupervised mode that detects switch

closures (Normally Open and Normally

Closed)

Analog Output IMP531-1ERS only

ENVIRONMENTAL

Operating Temperature

Environmental –40° to 60°C (–40° to 140°F)

Indoor –10° to 55°C (14° to 131°F)

Storage Temperature –40° to 70°C (–40° to 158°F)

Operating Humidity 5% to 95%, RH condensing (environmental

models)

5% to 90%, RH noncondensing (indoor

models)

Storage Humidity 20% to 80%, RH noncondensing

Shock and Vibration

Resistance IEC 60068:2-6 and 2-27

Impact Resistance IK10 (20 Joules)

Ingress Protection IP64 (Indoor models) & IP66/67, Type 4X

(Environmental models)

GENERAL

Construction Aluminum; polycarbonate bubble

Finish RAL 9003

Weight

Unit 0.86 kg (1.90 lb)

Shipping 1.20 kg (2.65 lb)

Pan/Tilt Adjustment Manual

Pan 0° ~ 370°

Tilt –15°~ –90°

Rotate 0° ~ 355°

NETWORK

Supported Protocols TCP/IP, UDP/IP (unicast, multicast IGMP),

UPnP, DNS, DHCP, RTP, RTSP, NTP, IPv4, IPv6,

SNMP v2c/v3, QoS, HTTP, HTTPS, SSH, SSL,

SMTP, FTP, 802.1x (EAP), and NTCIP 1205,

ARP, DDNS, ICMP, IGMP, RTCP, SFTP, SIP, TLS/

TTLS, WS-discovery

Users

Unicast Up to 5 simultaneous users depending on

resolution settings (3 guaranteed streams)

Multicast Unlimited users H.264/H.265

Security Access Password protected, HTTPS, IEEE 802.X,

Digest Authentication, IP Filtering

Software Interface Web browser view and setup

INTEGRATION

Video Management VideoXpert;

VX Toolbox;

Endura 2.0 (or later);

Digital Sentry 7.3 (or later);

Open API Third-party VMS through Pelco API, ONVIF

Profile S, Profile G, Profile Q, and Profile T

Mobile Application Pelco Mobile

Local Storage Capture 1-, 5- or 10-second video clips on

camera sabotage, motion detection, or alarm

input; record video continuously in the case of

network outage with option to overwrite;

access video through FTP protocol and ONVIF

Profile G

Camera Discovery VX Toolbox

Firmware Upgrade Web UI or VX Toolbox

Web Browser Support Microsoft

®

Internet Explorer

®

8.0, Mozilla

®

Firefox

®

3.5, Google

®

Chrome

™

61.0

and later

Multilingual User Interface English, French, German, Italian, Portuguese,

Arabic, Russian, Spanish, Turkish, Korean,

Simplified Chinese

Model

Power

Input

Power Consumption (Watts or VA)

Typical

Maximum

(Models

without IR)

Maximum

(Models with

IR)

IMP131

IMP231

12 VDC 4.3 W 5.4 W 8.4 W

24 VAC 4.4 W 5.3 W 7.9 W

PoE 5.2 W 9.6 W 12 W

IMP331

12 VDC 5 VA 5.4 VA 8.4 VA

24 VAC 5 VA 5.8 VA 7.9 VA

PoE 5.8 VA 9.6 VA 12 VA

IMP531

12 VDC 7.5 W 8.4 W 10.2 W

24 VAC 7 W 7.2 W 9.4 W

PoE 8.1 W 12 W 12 W

Model

Power

Input

Power Consumption (Watts or VA)

Typical

Maximum

(Models

without IR)

Maximum

(Models with

IR)

IMP131

IMP231

12 VDC 4.3 W 14.4 W 16.8 W

24 VAC 4.4 W 13.0 W 14.4 W

PoE 5.2 W 14.4 W 16.8 W

IMP331

12 VDC 5 VA 14.4 W 16.8 W

24 VAC 5 VA 13.0 VA 14.4 W

PoE 5.8 VA 14.4 VA 16.8 W

IMP531

12 VDC 7.5 W 16.8 W 19.2 W

24 VAC 7 W 14.4 W 15.8 W

PoE 8.1 W 16.8 W 16.8 W
