15
2018-08-16 #:180-9121-5 (2019-01-15)
Onboard LEDs
There are four on-board LEDs that indicate the following:
LED Indication
Green power (Pwr) Displays when the board is powered up and not in reset mode. Flashes during
rmware update process.
Green le system activity (BSY) Flashes any time there is le-system activity (on any storage device)
Blue WiFi ( ) Flashes when the player is connecting to the wireless network. Displays when
connected.
Red status (Err) Flashes a certain number of times to indicate which error is occurring. The ash
codes are described below.
2 Unspecied error.
3 Network recovery script is preparing to run on a device congured for
network recovery.
4 No upgrade le found.
5 Failed to load kernel module.
6 Board is not capable of running the current rmware version.
7 A piece of on-board hardware is not working correctly.
8 Problem releated to the storage device (either USB or Micro SD card)
9 Problem related to the registry/NAND
10 The autorun script encountered a load/run error.
11 Wi-Fi related error
12 Unable to nd a bootable image.
Onboard Switch
The on-board switch is connected to the GPIO02, which is pulled low when the service (SVC) button
is pressed. Conversely, a pull up on the button normally sets the GPIO02 to be pulled high.
Reset Switch
The on-board switch is connected to the reset circuit. Pressing down the reset button will send an
initial signal to the system software, and holding the reset button low for approximately 4 seconds will
cause a hard reset.
