7
PCE Instruments PCE Instruments | www.pce-instruments.com
‘NORMAL MODE’
When the power supply is connected, the instrument:
• activates the ‘conguration digits’, and displays the code for the actual
conguration (see section 5)
• the instrument is in ‘normal mode’ of operation
HOW TO ACCESS THE ‘CONFIGURATION MODE’ AND THE ‘TOOLS’ MENU
With the instrument in ‘normal mode’ of operation, there is access to the
‘conguration mode’ and the ‘tools’ menu.
• to access the ‘conguration mode’, press the ‘SQ’ (<) key for 1 second
(see section 10.2)
• to access the ‘tools’ menu, press the ‘UP’ (5) key for 1 second (see
section 10.3)
‘ECO’ FUNCTION (‘CONFIGURATION DIGITS’ ARE AUTOMATICALLY
POWERED OFF)
If there is no interaction from the operator for 60 seconds, the instrument
powers off the ‘conguration digits’. The decimal point remains active
(ashing), indicating that the instrument is working correctly.
HOW TO POWER ON THE ‘CONFIGURATION DIGITS’
To power on the ‘conguration digits’, press one of the front keys ‘SQ’
(<) or ‘UP’ (5). This will power on the ‘conguration digits’, and activate
the ‘normal mode’ of operation.
10. Operate the conguration system
CONFIGURATION SYSTEM
The Series PCE-SCI of isolated signal converters provide a fast and
easy conguration system, based on function codes.
‘CONFIGURATION DIGITS’
The instrument provides two numerical leds, to inform about the actual
state of the instrument, active input and output signal ranges, and error
codes (see section 11).
CONFIGURATION KEYPAD
The conguration keypad is located inside the instrument, behind the
removable front cover. To access the conguration keypad, remove
the input signal terminal, and open the front cover (see section 9). The
instrument allows to password lock the keypad functions, by activating
an access code (‘password’ function) (see section 10.4).
10.1. ‘Normal mode’ of operation
HOW TO ACCESS THE ‘CONFIGURATION MODE’
With the instrument in ‘normal mode’ of operation (see section 10.1),
press for 1 second the ‘SQ’ (<) key. The horizontal leds light from
bottom to top. When the upper led lights, the instrument activates the
‘conguration mode’.
If the key is released before activating the ‘conguration mode’,
the horizontal leds light downwards from top to bottom, and
the instrument returns to ‘normal mode’ of operation.
Inside the ‘conguration mode’ the decimal point is not active.
Inside the ‘conguration mode’, the ‘conguration digits’ display the code
of the active conguration (see section 5). Press the ‘UP’ (5) key to
increase the code.
• press once to increase the value in +1
• maintain the key pressed to automatically increase the value
When the desired code is reached, press the ‘SQ’ (<) key. The leds light
a round shape while new conguration is stored, and the instrument
returns to ‘normal mode’ of operation.
When exiting the ‘conguration mode’ without changes (‘rollback’
activation, selection of inactive codes, etc), the horizontal leds
light down from top to bottom, and the instrument returns to
‘normal mode’ of operation.
‘ROLLBACK’ FUNCTION
If there is no interaction from the operator for 60 seconds, the instrument
exits the ‘conguration mode’ and returns to ‘normal mode’ of operation,
discarding changes.
10.2. ‘Conguration mode’
