16
English
6.2 Connect to the scales
After the desired settings have been made and the settings dialog has been closed with a click
on the "Apply" button, the connection to the balance can be established by clicking on the
icon.
If the connection could be successfully established, the term "Connected" is displayed in green
on the status bar for the dynamic data.
If, however, no connection is established, the term "Disconnected" is displayed in red.
6.3 Disconnect from the scales
By clicking on the icon, an active connection to the selected balance can be terminated.
If you exit the software, all connections to the scales will be terminated and the configurations
will be saved. (see chapter 8).
6.4 List of scales
In the lower left part of the main window, all scales currently available in the software are listed.
Depending on what balance is selected, the corresponding series of measurements will be listed
above.
6.5 List of measurement series
In the upper left part of the main window all series of measurements which belong to the selected
balance are listed. A series of measurements can be selected by one click. The data and statistics
will then be updated, among other things (see also 6.7 Statistical data).
