User Manual EN

FLEX 6-E / 10-E / 16-E

FLEX 6-S3 / 10-S4 / 16-S6

987

1.6

1.4

1.5

2.6

2.4

2.5

FLEX 6-S3

Quantity

1.4 Enclosurelowerpartwithttedmountingrail 1

2.4

Enclosureupperpartwithttedhingedwin-

dow and captive enclosure screws

1

3 Quick reference guide 1

4 Hinge strap 2

5 Pan-head screw

DIN79814.8x13 4

6 Screw cover 2

7 Blindange 1

8 Flange gasket

97x80mm 1

9 Pan-head screw

DIN79814.2x16 12

FLEX 10-S4

Quantity

1.5 Enclosurelowerpartwithttedmountingrail 1

2.5

Enclosureupperpartwithttedhingedwin-

dow and captive enclosure screws

1

3 Quick reference guide 1

4 Hinge strap 2

5 Pan-head screw

DIN79814.8x13 4

6 Screw cover 4

7 Blindange 1

8 Flange gasket

97x80mm 1

9 Pan-head screw

DIN79814.2x16 16

FLEX 16-S6

Quantity

1.6 Enclosurelowerpartwithttedmountingrail 1

2.6

Enclosureupperpartwithttedhingedwin-

dow and captive enclosure screws

1

3 Quick reference guide 1

4 Hinge strap 2

5 Pan-head screw

DIN79814.8x13 4

6 Screw cover 4

7 Blindange 1

8 Flange gasket

97x80mm 1

9 Pan-head screw

DIN79814.2x16 24
