20 GB/IE
¾ Before you begin: Check whether
– the steel cable
14
is wound properly
around the drum
17
and whether
– the space between coils is less than the
diameter of the cable itself (Fig. D).
¾ Make sure the steel cable
14
passes the
maximum/minimum length levers
15
16
properly and without touching them (Fig. B).
Operation
NOTE
u The product has been outfitted with a
thermostat switch. During operation, it may
stop the motor
3
. The motor can be only
started again once it has cooled down.
Winding/unwinding the cable
(Fig. J)
¾ Winding the cable: Press the control
switch
8
upwards according to the arrow
indication
.
¾ Unwinding the cable: Press the control switch
8
downwards according to the arrow
indication
.
Lifting loads
¾ Lower the steel cable
14
so you can handle
it comfortably.
¾ Fasten the load to the hook
10
12
. Use
additional bungee cords where necessary.
The load’s centre of gravity must be beneath
the product.
¾ Wind up the steel cable
14
until it is only
taut. Then fully lift the load.
Maximum/minimum length
levers
NOTE
u The maximum/minimum length levers
15
16
are not intended to regularly stop
the product. Always attempt to stop the
product before it triggers one of these
levers.
Minimum cable length lever
When the steel cable
14
is fully wound up, the
minimum cable length lever
15
will be triggered.
The steel cable cannot be wound up any further. It
can only be unwound.
Maximum cable length lever
When the steel cable
14
is fully unwound, the
maximum cable length lever
16
will be triggered.
The steel cable cannot be unwound any further. It
can only be wound up.
Emergency off switch
(Fig. J)
¾ In case of an emergency, press the
emergency off switch
7
to stop lifting or
lowering operation.
¾ The product is then locked. To unlock the
product, turn the emergency off switch
7
slightly clockwise (in the direction of the
arrow) until it pops out.
Set-up as block and tackle
Setting up the product as a block and tackle
distributes the load to 2 pulleys. This allows twice
the weight to be lifted. However, the maximum
lifting height and speed are reduced by half.
