GB
IE
NI
5
Proper use
This device is only intended for the follow-
ing uses:
• Sawing plastic, wood and light metal
with firm support
• Sawing straight and curved cuts as well
as mitre cuts (only wood and plastic) of
up to 45°
• Only operate in dry areas.
Please note the information on saw blade
types.
Any other use that is not expressly permit-
ted in this instruction manual may pose
a serious hazard to the user and result in
damage to the device. The operator or
user of the machine is responsible for any
accidents or personal injury and/or mater-
ial damage to third parties or their prop-
erty. The machine is intended to be used
by do-it-yourselfers. It was not designed
for heavy commercial use. The warranty
is void in the case of commercial use. The
manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
The device is part of the X20VTEAM
series and can be operated with bat-
teries of the X20VTEAM series. Bat-
teries of the X20VTEAM series may
only be charged using chargers of the
X20VTEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Cordless Jigsaw
• 2 × Wood saw blade (Swiss made)
• 1 Metal saw blade (Swiss made)
• Parallel guide
• Slide shoe (pre-assembled)
• Splinter guard (pre-assembled)
• Guard cover (pre-assembled)
• Line guide adaptor (pre-assembled)
• Reducer piece (pre-assembled)
• Storage case
• Translation of the original instructions
The rechargeable battery and
charger are not included in deliv-
ery.
Overview
The illustrations for the
device can be found on
the front and back fold-out
page.
1Switch lock
2On/Off switch
3Handle (Insulated gripping surface)
4Battery holder
5Suction nozzle
6Reducer piece
7Notch
8Slide shoe
9Switch (dust blower function)
10Hexagon socket screw (not visible)
11Footplate
12Pendulum stroke switch
13Chuck
14Guide roller
15Parallel guide
16Wood saw blade
17Metal saw blade
18Mount (Parallel guide)
19Line guide adaptor
20Retaining screw
21Guard cover
22LED work light
23Release (Chuck)
24Recess in slide shoe
