13
NIIEGB
operating the appliance for longer pe-
riods of time or if the unit is not held or
maintained properly.
Warning! During operation, this
electric tool generates an electro-
magnetic fi eld which, under certain
circumstances, may impair the
functionality of active or passive
medical implants. To reduce the risk
of serious or lethal injuries, we rec-
ommend that persons with medical
implants consult their doctor and
the manufacturer of their medical
implant before operating the ma-
chine.
Assembly
Disconnect the plug before any
work on the equipment. There is a
risk of injury.
Assembling the Curved
Handle
For a simple installation, select cut-
ting height 20 mm (see „Adjusting
the cutting height“).
B
1. Remove the two pre-installed
butterfl y nuts (2b) from the lawn-
mower housing (7). Insert the
lower bar (3) into the slot on the
lawnmower housing (7).
2. Fix the bottom bar (3) using the
two screws and butterfl y nuts
(2b
).
C
3. Fix the U-shaped handle (1) to
the lower beam (3) with the en-
closed carriage bolts (16) and
two wing nuts with washers (2a).
4. Clip the cable holders (10) onto
the lower bar (3) and the U-
shaped grip (1) and use them to
fi x the appliance’s cable in place
(21).
5. Adjust the angle of the U-shaped
handle (1) by loosening the
wing nuts with washers (2a) and
selecting one of the three rec-
ommended settings, which are
shown next to the wing nut (see
detail illustration).
By releasing the two wing nuts
with washers (2a) for fastening the
handle, you can fold the bow-type
handle (1) downwards to store the
device.
Ensure that the appliance’s
cable (21) is not trapped.
Operation
D
Hanging On/Removing
the Grass Bag
1. To hang on the grass bag (4), lift the
collision guard (9) and hang on the
grass bag. Fold the collision guard
(9) onto the grass bag (4). It holds the
grass bag in the correct position.
2. To remove the grass bag (4), lift the col-
lision guard (9) and detach the grass
bag. Fold the collision guard (9) back
onto the mower housing.
Do not work with the lawn-
mower without the collision
guard or lawn box. There is
a risk of injury.
E
Level gauge
The level gauge (17) is located on the side
of the grass catcher (4).
