PMNF 1500 B2
GB
│
IE
│
7 ■
Supplementary notes
Approved cutting disc designs:
segmented diamond-coated discs with slits
between the segments with a maximum size
of 10 mm and a negative cutting angle:
Disc diameter: 125 mm
Disc thickness: 2.1 mm
Wear hearing protection!
Wear safety goggles!
Wear safety shoes!
Wear protective gloves!
Wear a dust mask!
Not approved for wet grinding!
Original accessories/auxiliary
equipment
■ Only use the accessories and additional equip-
ment that are specified in the operating instruc-
tions and are compatible with the appliance.
Before use
Setting the cut width of the diamond
cutting discs
♦ Loosen the locking screw .
♦ Push the depth stop upwards.
♦ Press the spindle lock and hold it down.
♦ Use the face spanner to loosen the locking
flange .
♦ Remove the locking flange .
♦ Set the desired cut width in accordance with
the number of blotters . Ensure that the flange
is set in place as the top intermediate layer
(see fig. F).
NOTE
►
There are several spacer washers available
for you. Ensure that the groove width is the total
of the spacer washers between the diamond
cutting discs and the thickness of the cutting
discs.
► Please make sure that the backing flange
is fixed well on the shaft. The backing flange
must rotate with shaft.
► Please make sure that diamond disc fixed
well on the flanges + .
♦ Tighten the locking flange using the face span-
ner . Press the spindle lock while doing this.
NOTE
►
When setting a cut width that is smaller than
the maximum cut width, you must use the
blotters on the fixing flange side for fixing
the cutting discs since the fixing flange cannot
fix the discs alone on the spindle due to the
thread length (see fig. G).
