– welding cables should be completely unwound and installed
parallel on the floor, if possible
– if possible, devices and systems at risk from interference
radiation should be removed from the work area or shielded.
z Before using the device
Take the device and accessories out of the packaging and check them for damage (e.g. transport damage).
Fix the carrying strap
1
onto the device (see Fig. C1 – C4).
Connect the electrode holder
5
and the earth terminal
4
to the welding device.
Position an electrode in the clamps of the electrode holder.
z Fit welding mask
Fit the handle
8
onto the welding mask
7
, as shown in Fig. A.
Fit the protective glass
11
onto the welding mask
7
, as shown in Fig. B.
The protective glass
11
must be pushed in from the top.
NOTE: If you are not able to push the protective glass
11
in fully, gently press on the outside of the
protective glass
11
.
z Using the device
NOTE: The welder is designed for welding with electrodes.
Use the electrode holder clamps without protruding bracket screws, which meet the current safety
standards.
Make sure that the ON/OFF switch
9
is set to position “O” (“OFF”) or that the mains cable
10
is
not plugged into the socket.
Connect the welding cable according to its polarity and in accordance with the specifications of the
electrode manufacturer.
To do this, connect the connector of the earth terminal
4
with the relevant output on the inverter
welder (marked with “-”).
Connect the connector of the electrode holder
5
with the relevant output on the inverter welder
(marked with “+”).
Put on appropriate protective clothing in accordance with the specifications and prepare your
workplace.
Connect the earth terminal
4
to the workpiece.
Clamp the electrode into the electrode holder
5
.
Switch the device on by setting the ON/OFF switch
9
to the “I” (“ON”) position.
Adjust the welding current using the rotary knob
3
depending on the electrode being used.
NOTE: See the following table for information on the recommended welding current to be used,
depending on the electrode diameter.
Ø Electrode Welding current
1.6 mm 40–60 A
2.0 mm 60–80 A
2.5 mm 80–100 A
