17GB/IE/NI/CY
wire welder or parts show any damage.
If this is the case, do not use the inverter
flux cored wire welder. Contact the
manufacturer via the indicated service
address.
Remove all protective films and other
transport packaging.
Check that the delivery is complete.
z Assembly
z Assembling the welding
protection shield
Insert the dark welding lens
21
with the
writing facing up into the shield body
20
(see Fig. C). The labelling on the dark
welding lens
21
must now be visible from
the front of the protective shield.
Push the handle
22
from the inside into
the corresponding notch of the mask,
until it snaps into place (see Fig. D).
z Inserting the flux cored wire
Always unplug the mains
plug from the mains socket prior to each
maintenance task or preparatory work in
order to prevent the risk of an electric shock,
injury or damage.
Note: Different welding wires will be
needed depending on the application.
Welding wires with a diameter of
0.6–1.0 mm can be used with this device.
Feed roll, welding nozzle and wire cross-
section must be compatible with one another.
The device is suitable for wire reels weighing
up to maximum 1000 g.
Unlock and open the cover of the wire
feed unit
1
by pushing the latch up.
Unlock the roll unit by pressing on the roll
holder
29
and turning it anticlockwise
(see fig. F).
Pull the roller holder
29
and washer off
the shaft (see fig. F).
Note: Make sure that the end of the wire
does not come loose and cause the roll to
roll out on its own. The end of the wire may
not be released until during assembly.
Completely unpack the flux cored wire
welding spool
17
, so that it can unrolled
without difficulty. Do not release the wire
end yet (see Fig. G).
Place the wire reel on the shaft. Make
sure that the roll unwinds on the side of
the
31
wire feed guide (see Fig. G).
Replace the washer and the roller holder
29
and lock them by pressing and
turning clockwise (see fig. G).
Undo the adjustment screw
27
and swing
it downwards (see Fig. H).
Turn the thrust roller unit
28
to the side
(see Fig. I).
Loosen the feed roll holder
30
by turning
it anti-clockwise and pull it forwards and
off (see Fig. J).
On the top of the feed roll
19
, check
whether the appropriate wire thickness is
indicated. If necessary, the feed roll has to
be turned over or replaced. The supplied
welding wire (Ø 0.9 mm) must be used
in the feed roll
19
with the specified wire
thickness of Ø 0.9mm. The wire must be
positioned in the front groove!
Erect the feed roll holder
30
again and
screw in a clockwise direction.
Remove the burner nozzle
9
by turning
it anti-clockwise (see Fig. K).
Unscrew the welding nozzle
15
(see Fig. K).
Guide the cable assembly
12
away from the welder as straight as
possible (place it on the floor).
Take the wire end out of the edge of the
spool (see Fig. L).
Trim the wire end with wire scissors or
a diagonal cutter in order to remove the
damaged, bent ends of the wire
(see Fig. L).
Note: The wire must be kept under
tension the entire time in order to avoid
a releasing and a roll out! Therefore it is
