GB

MT

23

Note

An incorrect battery can damage the ma-

chine and the battery.

Inserting the battery (Fig.A)

1. To insert the battery (14), push the bat-

tery (14) along the guide rail (17) into the

appliance. You will hear it click into place.

Removing the battery (Fig.A)

1. Press the battery release (13).

2. Pull the battery (14) out of the appliance.

3. Let go of the battery release (13).

Operation

Working instructions

CAUTION! Risk of injury. Do not oper-

ate the appliance if damaged or incorrectly

assembled! Replace damaged parts and

dirty filters (see Spare parts and accessories,

p.27).

• Also inspect the appliance for visual dam-

age.

• Ensure that the collection container (1) fil-

ter holder (3) and filter (4) are dry when

changing directly from wet vacuuming to

dry vacuuming!

• Only vacuum liquid up to the “Maximum

fill level” mark (2).

• Always hold the appliance vertically dur-

ing transport, otherwise liquid will leak

out! Hold the attached wet nozzle (10)

downwards.

Switching on and off

Note

Before switching on, check whether the filter

holder (3) and filter (4) are inserted and dry

(see Attaching and removing the filter holder/

filter, p.22).

Switching on (Fig.A)

1. Push the on/off switch (6) forwards.

Switching off (Fig.A)

1. Pull the on/off switch (6) backwards.

Cleaning, maintenance and

storage

WARNING! Risk of injury due to unin-

tentional start-up. Protect yourself when

performing maintenance or cleaning work.

Switch off the device and remove the battery

(14).

You should have any repair and maintenance

work that is not described in these instruc-

tions carried out by our Service Centre. Only

use original replacement parts.

Cleaning

General cleaning

WARNING! Electric shock! Never spray

down the device with water.

Notes

• Risk of damage. Chemical substances

may attack the plastic parts of the ma-

chine. Do not use any cleaning agents or

solvents.

• Make sure to keep the ventilation open-

ings free of foreign objects.

• Clean the surface of the appliance with a

soft brush or cloth.

• Empty the collection container (1) after

every use.

• Clean the collection container (1) with a

damp cloth.

Cleaning the filter

(Fig.A)

1. Remove the collection container (1), see

Attaching and removing the collection

container, p.22.

2. Remove the filter holder (3) / filter (4), see

Attaching and removing the filter holder/

filter, p.22.

3. Tap the filter (4) and clean it with a brush

or compressed air.

4. You can also clean a heavily soiled filter

(4) under running water. The filter (4) must

be completely dry before reuse.

5. If the filter (4) is too dirty, replace it with

a new filter (4) (see Spare parts and

accessories, p.27).

6. Fit the filter holder (3) / filter (4), see

Attaching and removing the filter holder/

filter, p.22.

7. Attach the collection container (1), see

Attaching and removing the collection

container, p.22.

Maintenance

Replacing the filter

Replace an excessively dirty filter (4) with

a new one. New filters can be acquired
