PFBS 160 C3
GB
│
IE
│
11 ■
Function Accessories Use
Protrusion
(min–max) mm
Engraving
Engraving bits
Labelling, handicrafts 18–25
Polishing, rust removal
CAUTION! Exert only
a light pressure when
applying the tool to the
workpiece.
Metal brush
rust removal 9–15
Polishing
attachments
Various metals and plastics, espe-
cially precious metals such as gold
and silver
12–18
Cleaning
Synthetic brushes
e.g. cleaning hard-to-access
plastic housings or the area
around a door lock
9–15
Grinding
Grinding discs
Grinding work on stone, wood,
fine work on hard materials such
as ceramics or alloyed steel
12–18
Grinding bits
10
Abrasive belts
10
Cutting
Cutting discs
Working metal, plastic and wood 12–18
■ Note that the maximum diameter of the grinding
assembly and of grinding cones, pencil grinders
and grinding points with a thread insert may not
exceed 55mm and the maximum diameter for
sandpaper sanding accessories may not exceed
80mm.
NOTE
► The max. permissible length of a mandrel is
33 mm.
■ Store the accessories in the original box or store
the accessory components somewhere else to
protect them from damage.
■ Store the accessories somewhere dry and not
in the vicinity of aggressive media.
■ If you exert too much pressure, the fitted tool can
break and/or the workpiece could be damaged.
You will achieve optimum working results by
moving the tool over the workpiece at a steady
speed and while exerting light pressure.
■ When carrying out cutting work, hold the appli-
ance firmly with both hands.
■ Observe the data and the information in the
table to prevent the end of the spindle from
touching the perforated base of the grinding tool.
Flexible shaft
■ Never operate the spindle lock while the motor
is running. Otherwise the appliance or the
flexible shaft could be damaged.
♦ Unscrew the union nut
anticlockwise off the
appliance and store it carefully.
♦ Press the spindle lock
and hold it down.
♦ Screw the tensioning nut
anticlockwise off
the appliance.
♦ The shaft needs to be pulled out a short distance
as it cannot be fixed into the collet chuck
otherwise.
♦ Fit the flexible shaft
onto the appliance.
To do this, the internal access of the flexible
shaft push the tensioning nut into the collet
chuck .
♦ Press the spindle lock
and hold it down.
♦ Now, tighten the tensioning nut
using the
combination spanner .
Now, screw the union nut
14b
of the flexible
shaft clockwise onto the appliance.
♦ Place the desired accessory into the collet
chuck
, of the flexible shaft.
