ELECTRIC PLANER PEH 30 D4
Introduction
Congratulations on the purchase of your new
appliance. You have chosen a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product,
please familiarise yourself with all operating and
safety instructions. Use the product only as
described and for the range of applications speci-
fied. Please also pass these operating instructions
on to any future owner.
Intended use
The appliance is designed for planing workpieces
such as beams or planks that are firmly held in
place. The appliance is also suitable for cham-
fering edges and for grooving. Any other uses of or
modifications to the appliance are deemed to be
improper usage and may result in serious physical
injury. The manufacturer accepts no responsibility
for damage(s) attributable to misuse. This appli-
ance is not intended for commercial use.
Equipment
Safety lock-out
ON/OFF switch
Chip ejector (optionally right/left)
Belt cover
Screws for belt cover
Rip fence
Fastening screw for rip fence
Lock nut for setting the fold width
8a
Connecting piece
8b
Connecting screw
8c
Washer
Plane sole
V grooves
Fastening screw for the fold depth stop
Fold depth stop
Dial for setting the cut depth (additional handle)
Cut depth scale
Adapter for external extraction
Parking shoe
Cutter block
Clamping element
18a
Hex screws
Fastening screw for the planing blade
Planing blade
20a
Tensioning plate groove
Lateral cutter block guard
Hex key
Drive belt
Large belt wheel
Small belt wheel
Open-ended spanner
Package contents
1 electric planer
1 guide fence
1 fold depth stop
1 hex key
1 open-ended spanner
1 adapter for external extraction
1 operating manual
